Mand Labs Circuit Workbook KIT-1 (pack of 60 circuits)

Name: Mand Labs Circuit Workbook KIT-1 (pack of 60 circuits)
SKU: 7941
Availability: InStock

Top rated product

Mand Labs Circuit Workbook KIT-1 contains a pack of 60 circuit diagrams and worksheets. Learners and students can use the workbook to record their observations and readings, refer to the circuit schematics and components used in it, and follow the activities in a modular progression, building upon the fundamentals of electricity, electronics and semiconductors.

$29.99 Excluding tax

Category: Books and Manuals

Description

Mand Labs Circuit Workbook KIT-1 contains a pack of 60 circuit diagrams and worksheets. It was orginally designed to be used for live hands-on workshops in classrooms and caters to individual learners as well. The booklet starts with schematic symbols and lists all the projects and activities in a structured format.

Learners and students can use the workbook to record their observations and readings, refer to the circuit schematics and components used in it, and follow the activities in a modular progression, building upon the fundamentals of electricity, electronics and semiconductors. The workbook was used to train over 5000 high school students and 100s of school educators in DIY workshops.
